Tile grout quantity
Estimate grout mass from tiled area, tile dimensions, joint width and filled depth. Enter mixed-product density and an allowance. The model calculates the joint area once, avoiding double-counting where horizontal and vertical joints meet.
Free to use. No email or account required.
Your inputs
The editable example is illustrative. Enter your own dimensions, operating data, prices, and fees. Results update as you edit.
Calculations run in your browser. Inputs are not saved or sent to analytics.
How it works
- Joint area share = (1 − ( × ) ÷ (( + ) × ( + ))) × 100
- Mixed grout mass with allowance = × × (Joint area share ÷ 100) × × (1 + ÷ 100)
- Worked example
- 10 × 8 × (1 − 300² ÷ 303²) × 1.6 × 1.1 ≈ 2.774317 kg
Input and formula key
Your result
Complete the inputs to see your result.
Assumptions and limitations
Uniform rectangular tiles form an infinite repeating grid; perimeter corrections, irregular joints and deep voids are excluded. Density must describe mixed grout in kg/L, not dry powder bulk density. Manufacturer coverage and recommended depth take precedence over this estimate. The result is mixed mass, not dry powder bag weight.
Sources
- MAPEI — grout coverage and product-specific density guidance Sources reviewed: 2026-10-28
